Revit 2018: Multi-storey stair update:

Autodesk has given us many new updates with the new Revit 2018 release. One of the very useful updates of such is the "Multi-storey" settings of the stairs. If you have used Revit(2015 and later) for a while, you must be familiar with the multi-storey option available to simply create a single stair(core) for all the floors. But it had an issue if the floors are of different heights.

So the new 2018 update solves this issue and provides us the multi-storey stair for all the floors irrespective of the individual floor height. The best part of this is, it's parametric, i.e., you can change the parameters like height, width, landing length etc., and see all the stairs update along with it. The information in the help website gives a detailed explanation of the update.

The following video tutorial show how to use the feature.

Comments

Power Query - "SUBSTITUTE" Function: Remove/Replace multiple values in a column in One Step.

Often times, when you get data from a source, there will most probably be something incorrect that needs to be fixed using an ETL process of Power Query. And most of those transformations would require either Replacing or Removing string's that are not necessary. For example, if you extract any financial data from a source which has multiple currency symbols, there's a chance that the numbers get extracted along with the currency symbols like "$700"/"€700" instead of 700. And these type of cases makes it tough to Transform the Data to our wish as the value will be considered as a text instead of a number. In those type of cases, we would most likely have to create multiple steps to remove the multiple currency symbols from the Column. But thanks to the solution provided by Marcel for one of the questions posted on Stack Overflow, with a little manipulation of the Query language (M), we can replace/Remove multiple strings in one step using the List. ...

Grasshopper: Voronoi Holes on a Planar surface

One of the best natural examples for a Voronoi is the Wing structure of a dragon fly.Grasshopper can help us to build a shape like this in Rhino. Image Courtesy: The Pond blog Grasshopper by default has a node for Voronoi, we just have to prepare the necessary information to feed into the node. The following example shows how to create a Voronoi shaped holes in a surface Create a planar Surface from rhino or grasshopper Randomly Populate the surface with points using the Populate 2D Node Feed the surface and the points into the Voronoi node and feed a number slider too to adjust eh radius This forms the required Voronoi structure which you can edit the number of points or radius. To create the holes we need to offset each and every inner portion towards its centre using the Scale node We can find the centre of each of the inner portions using Area node I'm not sure why but using the offset command su...

Grasshopper: offsetting curves on surface vs scaling curves on surface

Though in Grasshopper Offset and Scale are two different node functions, when it comes to a planar surface, the results of the both are similar. But, I found the " Scale" node to be effective when you want to loft the resultant curve with another. The following images show the different results of a Voronoi structure that yielded when scale and offset nodes are used. When the Offset node is used When Scale is used

Scribble on your PC/Mac screen with these annotation tools

While you are in a presentation or hosting a webinar, you might want to write/highlight a part of your screen to draw the attention of your audience on something important. Although you can use the tools from powerpoint to scribble in the PPT file, you might want to write something on other apps as well. That's where these awesome apps come into play. Although these apps have similar features, you might prefer one above the other. ZoomIt : ZoomIt is an application developed by Microsoft which can be installed from the following link . It is a free tool with features like Text, Shapes, whiteboard, blackboard, zoom . When activated, the tool converts the current screen into a static image and allows you to draw/write on it. One the tool is activated, you can also choose to create a whiteboard/blackboard screen on your PC to draw on. Although the colors are limited to 6 colors: Red (R) , Green (G) , Blue (B) , Orange (O...
